CHIPSETAMD X670 CPUSupports AMD Ryzen 8000/ 7000 Series Desktop Processors Socket AM5 MEMORY4x DDR5- Maximum Memory Capacity 256GB Memory Support DDR5 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz Max. overclocking frequency: 1DPC 1R Max speed up to 7800+ MHz 1DPC 2R Max speed up to 6400+ MHz 2DPC 1R Max speed up to 6400+ MHz 2DPC 2R Max speed up to 5400+ MHz Supports Dual-Channel mode Supports non-ECC- un-buffered memory Supports AMD EXPO AUDIORealtek ALC4080 Codec 7.1-Channel USB High Performance Audio Supports S/PDIF output Supports up to 32-Bit/384 kHz playback on front panel STORAGE4x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 - supports 22110/2280 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 - supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 - supports 2280/2260 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 - supports 2280/2260 devices 6x SATA 6G LANRealtek RTL8125BG 2.5G LAN ONBOARD GRAPHICS1x HDMI Support HDMITM 2.1 FRL- maximum resolution of 4K 120Hz* 1x DisplayPort Supports DP1.4- maximum resolution of 4K 60Hz* 1x Type-C DisplayPort Supports DisplayPort 1.4 with HBR3- maximum resolution of 4K 120Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. SLOT3x PCI-E x16 slot Supports x16/x4/x2 (For Ryzen 7000 Series processors) Supports x8/x4/x2 (For Ryzen 7 8700G and Ryzen 5 8600G processors) Supports x4/x2/x2 (For Ryzen 5 8500G processor) 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From CPU) PCI_E4 Gen PCIe 4.0 supports up to x2 (From Chipset) RAIDSupports RAID 0- RAID 1 and RAID 10 for SATA storage devices* Supports RAID 0- RAID 1 and RAID 10 for M.2 NVMe storage devices *SATA_A1 & SATA_A2 do not support RAID function. USB4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 4x USB 5Gbps Type A (Front) 2x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) 1x USB 10Gbps Type C (Front) 1x USB 20Gbps Type C (Rear) WIRELESS LAN & BLUETOOTHAMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz- 40MHz- 80MHz- 160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.3** * Wi-Fi 6E 6GHz may depend on every countrys regulations and will be ready in Windows 11. ** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11. INTERNAL IO1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 6x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports LED FEATURE4x EZ Debug LED BACK PANEL PORTS DisplayPort USB 3.2 Gen 2 10Gbps (Type-A) USB 3.2 Gen 1 5Gbps (Type-A) 2.5G LAN Wi-Fi / Bluetooth Audio connectors Flash BIOS Button HDMI USB 3.2 Gen 2 10Gbps (Type-C Display port) USB 3.2 Gen 2x2 20Gbps (Type-C) USB 3.2 Gen 2 10Gbps (Type-A) S/PDIF-OUT OPERATING SYSTEMSupport for Windows 11 64-bit- Windows 10 64-bit PCB INFOATX 243.84mmx304.8mm
